Ferrocement Elevations
 Ferrocement fins elevation treatment to a residential  building 20 floors. Size 3.0x0.125x0.4 Mt.h. wire  mesh  is avoided for workability. Light structural  steel welded  panels.
 These are elevation treatment fins to office  building. the fins are 40mm thick and 3.75Mtr. long  attached to the building, using ferrocement cleats  and stainless steel bolts.


Horizontal elevation back view.
  Thin Horizontal elevation for multistory building.


 Horizontal elevation enlarge
 Ferrocement fins elevation treatment to residential  building 8 floors. Size 2.4x20x0.65M.th. Wiremesh  is  avoided for workability. Corrosion resistant  welded  steel framework and fiber reinforced  cement matrix  with 12 mm size aggregate is used.



 This is an elevation of horizontal pyramid consisting of ferrocement panels hallow behind. The pyramid is  attached to the side of the water tank.

  FERROCEMENT PERGOLA
 - Ferrocement Pergola resting on curved RCC beam and straight beam on 2 sides.
 - The pergola is consisting of hollow Ferrocement section manufactured on machinery set up under     controlled conditions.
 - The quality of the work is assured in view of machinery manufactured.
 - The accuracy has to be correct to 1 or 2 mms in view of the fact that there is no plaster in the pergola     system
 - The pergola is very much durable since Ferrocement is highly strong, water proof and manufactured    with stringent material as well as labour specifications.
